Product Description
The UI-1542LE Rev. 2 is no longer available for purchase, please contact us for replacement options.
1.31 MPix CMOS sensor (MT9M001STM) from onsemi delivers the best price/performance ratio. Besides offering a megapixel resolution of 1280 x 1024 px pixels, it also features horizontal and vertical subsampling modes for higher frame rates.
The large pixels create an extremely good signal-to-noise ratio and therefore produce a high image dynamic.
Note: This USB 2.0 Rev. 2 camera works reliably on fast USB 3 ports.
Sensor
|
Sensor Technology |
CMOS |
|
Resolution (h x v) |
1280 x 1024 |
|
Bit depth |
8 bit |
|
Sensor Size (format) |
1/2” |
|
Shutter |
Rolling shutter |
|
max. fps in Free-run Mode |
25 |
|
Pixel size |
5.2μm |
Design
|
Interface |
USB 2 |
|
Lens Mount |
|
|
Dimensions H/W/L |
36 mm x 36 mm x 5.7 mm |
|
Weight |
12 g |
|
Power supply |
USB cable |
