Product Description
The EinScan H2, the newest edition to the Shining 3D EinScan handheld scanners! The EinScan H2 improves on its predecessor with a 5MP resolution texture camera, enhanced accuracy, and 3 infrared VCSEL projectors for more photorealistic textures and better quality data. Its wide scanning area and adjustable working distance make it suitable for various scenes and objects, both small and large, in narrow or wide spaces. The EinScan H2 is an efficient 3D scanning tool that can revolutionize your workflow See the DATA SHEET here.
Be sure to check out the EinScan Trade-In and upgrade program to get your EinScan H2 today!
Key features include:
5MP Texture Camera
Captures rich, bright colors and clean textures for photorealistic 3D models.
3 VCSEL Projectors
Provide superior material and lighting adaptability, effortlessly handling various surface types and scanning environments.
Hybrid Light Source+
Dual light sources improve scanning efficiency, LED light offers fast 3D scanning with accurate, high-quality data.
- Various scenes from small to large
- Scanning speed: 1,200,000 points/s
- Accuracy: Up to 0.05mm
- Point distance: Up to 0.2mm
Infrared VCSEL is ideal for capturing dark surfaces, for human body scanning, and for bright-lit environments.
- Dark color objects
- Human body scan
- Outdoor scan
- Accuracy: Up to 0.1mm
- Point distance: Up to 0.2mm
Ultra-Wide FOV and Adjustable Working Distance
- Adjustable working distance enables working distance adjustment from 200mm to 1500mm, to adapt to narrow or wide scenes and objects of various sizes.
- FOV (Field of View) up to 780mm x 900mm offers flexibility in scanning volume to capture large-sized objects quickly.
- Marker-free scanning scans rich geometric features without the hassle of markers.
Optimized for Face and Body 3D Scanning
- Flashless infrared technology ensures optimal comfort during face and body 3D scanning.
- Advanced hair enhancement algorithm is designed to successfully capture light and dark hair...
- Non-rigid algorithm in IR Mode captures 3D body data quickly and seamlessly, with auto-compensation of slight movements to eliminate misalignment risks
User-Friendly Design
- Remarkable scanning software delivers a professional easy-to-use 3D scanning interface with automated processing, intuitive UI design, and intelligent data quality indicators.
- Ergonomic design makes the EinScan H2 portable, easy to grasp, and intuitive to operate.
Develop Your Own Scanning App with EinScan H2 SDK
- The Einscan H2 scanning SDK is available and open for customization. Integrate our powerful scanning and data processing into your self-developed software or app.
