Product Description
VC-12MX-M/C 330 F The Fastest Speed & High Resolution CMOS Digital Camera with CoaXPress Interface
The VC-12MX-330 F camera, the latest member of the industry proven VC series, is based on the latest CMOS global shutter imager. Equipped with the Vieworks’ innovative technologies proved by the world’s top FPD manufacturers, this camera offers not only the highest frame rate but also highly uniformed images. This camera supports 12 megapixel resolutions with frame rate up to 335 fps (CoaXPress - 8 Channels). Its CoaXPress interface supports transmitting image data at up to 25 Gbps using four coaxial cables and up to 50 Gbps using eight cables. Featured with high quality image uniformity and high resolution, this camera is ideal for wide range of demanding applications including FPD, PCB and semiconductor inspections.
MAIN FEATURES
- 12 Megapixels Resolution
- High-Speed Progressive Scan CMOS Imager
- Global Shutter CMOS Technology
- CoaXPress Interface up to 335 fps at 50 Gbps using 8 CH
- Flat Field Correction
- Low Noise with Optimized Heat Treatment
APPLICATIONS
- FPD and Electronics Inspection
- Semiconductor Inspection
- Research and Scientific Imaging
- Document / Film Scanning
