Product Description
VC-12MX-M/C 65H High Speed & High Resolution CMOS Digital Camera with CoaXPress Interface
The VC-12MX-65 cameras, the latest members of industrial proven VC series, are based on the latest CMOS global shutter imagers. The cameras feature 12 megapixel resolution with frame rates of up to 65 fps. These combinations of resolution, frame rate, and global shutter set a new standard for Industrial, Scientific, and Surveillance digital imaging applications. Customers in the industrial market can take advantage of common coax cabling to transmit images at rates and distance above and beyond previous standards. With these cameras, image data can be transmitted at up to 6.25 Gbps using a single coaxial cable and up to 12.5 Gbps using two cables. These high speed and high resolution models are ideal for wide range of demanding applications including PCB and semiconductor inspections. For efficiency, Vieworks provides this amazing product in two different types, the straight type and the right-angle type, with the same specification.
MAIN FEATURES
- 12 Megapixel Resolutions
- High-speed Progressive Scan CMOS Imager
- Global Shutter CMOS Technology
- CoaXPress Interface up to 64.6 fps at 12.5 Gbps using 2 CH
- Flat Field Correction
- Low Noise with Optimized Heat Treatment
APPLICATIONS
- PCB Inspection
- Semiconductor Inspection
- 3D Inspection
- High-end Surveillance
