Product Description
Model Description RADEV5MCLSF- Matrox Radient eV-CL single-Full Camera Link PCIe 2.1 x4 frame grabber with 512 MB DDR SDRAM and HDR26 (mini Camera Link) connectors. Includes cable adaptor (auxiliary I/O).
DATA SHEET
Matrox® Radient eV-CL is a series of Camera Link® frame grabbers with the most comprehensive features currently available in the industry. The frame grabber line-up offers reliable image acquisition, extended cable length support, and high frame-rate image capture that will extend the effectiveness of the Camera Link standard for years to come.
- Support the most high-performance Camera Link cameras with available support for Full and 80-bit mode at up to 85 MHz
- Perform deterministic image acquisition by way of the jitter-free Camera Link 2.1 interface
- Maximize system compatibility with the choice of PCIe® 2.1 x4 or x8 connectivity
- Eliminate missed frames with ample onboard buffering and PCIe bandwidth
- Optimize multi-camera applications via support for up to four Base or two Full/80-bit Camera Link cameras per board
Comprehensive Camera Link frame grabbers
Zebra® Radient eV-CL is a series of Camera Link® frame grabbers with the most comprehensive features currently available in the industry. The frame grabber line-up offers reliable image acquisition, extended cable length support, and high frame-rate image capture that will extend the effectiveness of the Camera Link standard for years to come.
Versatile high-performance image acquisition
The Zebra (formerly Matrox) Radient eV-CL series is capable of handling image capture from a single lowest data-rate Camera Link device to multiple maximum-bandwidth Camera Link cameras. With the possibility of interfacing up to four Base or two Full/80-bit mode Camera Link cameras at up to 85 MHz on a single board with PoCL support, the Zebra Radient eV-CL provides users with the flexibility to configure systems to best match imaging needs while simplifying overall setup. A PCIe 2.1 x4 or x8 host interface provides the throughput necessary to ensure the continuous flow of pixels to host memory while also giving flexibility in the choice of host computer. With a peak bandwidth of up to 2 or 4 GB/s, the host interface prevents pixels from inadvertently being discarded. Furthermore—via a programmable option—the Zebra Radient eV-CL is capable of handling applications where image-capture rates exceed the tens of thousands of frames per seconds, all without host intervention. The Zebra Radient eV-CL series is also designed to work at extended cable lengths, allowing cameras to be placed at distances previously not possible from the computer while maintaining the same maximum throughput.
Lifecycle managed for consistent long-term supply
Each component on the Zebra Radient eV-CL has been carefully selected to ensure product availability in excess of five years. The Zebra Radient eV-CL is also subject to strict change control to provide consistent supply. Longevity of stable supply lets OEMs achieve maximum return on the original investment by minimizing the costs associated with repeated validation of constantly changing products.
Field-proven application development software
The Zebra Radient eV-CL series is supported by Aurora Imaging Library, formerly Matrox Imaging Library (MIL), a comprehensive collection of software tools for developing industrial imaging applications. Aurora Imaging Library features interactive software and programming functions for image capture, processing, analysis, annotation, display, and archiving. These tools are designed to enhance productivity, thereby reducing the time and effort required to bring solutions to market. Refer to the Aurora Imaging Library datasheet for more information
