The VCS-14MX2-M/C340I camera offers 338 frames per second at 4,608 × 3,072 resolution. It delivers not only fast frame rates but also highly uniform images. With CoaXPress 2.0 interface, it can transmit
image data at up to 50 Gbps using four coaxial cables. The back-side illuminated sensor significantly enhances image sensitivity. Combining high speed and high performance, the VCS-14MX2-M/C340I
camera is an excellent choice for applications that require high data rates and resolutions—such as flat panel display, PCB, and semiconductor inspections. For a wide range of choice, this amazing product is provided in two different types: a fan type and a heat sink type, both with the same specification.
Key features include:
- High resolution of 4608 × 3072 pixels, for detailed imaging and inspection tasks.
- A maximum frame rate of 340 frames per second (fps), for capturing fast-moving objects or processes.
- A GSPRINT 5514 CMOS image sensor with a pixel size of 5.5 μm.
- Global shutter technology to capture images of moving subjects without distortion.
- A Camera Link interface for high-speed data transfer.
- Available in monochrome (VCS-14MX2-M) and color (VCS-14MX2-C) versions.
Potential Applications:
The Vieworks VCS-14MX2-M/C340 I is suitable for applications requiring high speed and high resolution, such as:
- Industrial inspection and quality control to detect manufacturing defects.
- Scientific research and analysis for experiments or detailed analysis.
- Microscopy for biological studies or examining microscopic structures.
- Metrology for precise measurements and analysis.
- Automation for object recognition or positioning.
